THERM O WEB LS 62 LAMINATING SYSTEM

MA ID:	LFL - 12657
Price:	$31,500.00
Category:	Wrap/Foil/Roll
Manufacturer:	Therm O Web
Model:	LS 62
Year of Manufacture:	2009
Condition:	Very Good
Electric:	480 Voltage 60 Cycle 3 Phase
GREAT MACHINE OPTION IN A COMPLETE LINE FOR LAMINATING PANELS. CLEAN MACHINE VERY LITTLE USAGE. Applications: Face/Laminate material: Rolled stock, paper, melamine, HP Laminate and wall coverings. Substrate: Foam, Particle board, MDF, Plywood, Hardwoods and Fiber board. System Operation: Step 1- Operator feeds substrate through glue applicator. Pinch roller disperses the glue web as substrate advances. Once glue has been applied hot knife wire with separate the glue. Step 2- Index laminate manually positioned to adjusting index pin and activates the laminate drive. Step 3- Heat bank substrate passes under the tripple heat bank which activates the glue web. Step 4- Laminate of board as face material and substrate meet and enter pinch roller where the bond is made advancing through the pinch roller together to complete the laminate. Working dimensions: Maximum Substrate Width: 62";Minimum Substrate Widths: 12"; Maximum Substrate Length: 12' (if using Glue Web cutoff); Minimum Substrate Length: With Carrier: 12";With-Out Carrier: 27" and With Laminate Drive: 54". Substrate Thickness: 1/8" - 4";Minimum Laminate Widths: 12";Minimum Laminate Length: 12" and Feed Rate Per Minute: up to 40'. Materials must be acclimated to room temperature (no less than 65 degrees) prior to use. Note: Additional pinch roller height can be accommodated up to 6"and * Materials under 52" must be fed manually. Features: 40 FPM 4" Pinch Roller Opening Triple Heat Banks Digital Pinch Roller Height Idicator Heavy 2 1/2" Conveyor Rollers Temp Control with LED Readout included in PLC Control Laminate Drive System Pneumatiac Hot Wire Cutoff System PLC Touchpad Control Auto Cool Down Auto Shut Down 12' Panel Capability Stainless Steel Trim Finish Standard Equipment: 4" Height Capacity Triple Heat Banks Digital Height Readout Heavy 2 1/2" Diameter Rollers Substrate Drive Glue Web Dispensing System Digital Heat Readout PLC Control Panel Hot Wire Cutoff Laminate Drive System Auto Shutdown Auto Cool Down. TO INCLUDE: INFEED/OUTFEED 5' CONVEYOR Machine layout:** Length: 26' x Width (base): 6' x Height: 5.5'
Shipping Footprint:	30 (length) x 7 (width) x 9 (height)

All Information including Photos and Videos are supplied by a 3rd party Source.
Please confirm all data before committing to a purchase.
*Subject to credit approval. Additional programs available.
