NEW Alberti T-Flight CNC Feed Through Point to Point

MA ID:	PTP - 12747
Price:	$99,300.00
Category:	Point to Point Point to Point
Manufacturer:	Alberti
Model:	T-Flgiht
Condition:	New
Electric:	400 Voltage 60 Cycle 3 Phase
"Point to Point" Feed Through Feed NC Vertical Boring Machine model T-FLIGHT-SH/Cn (working from the Top) with manual feeding and longitudinal/unloading and longitudinal panel transfer. Monolithic high rigidity frame in welded high thickness steel plate. Independent management of all machine axes with boring cycle optimization. 4 Independent Controlled Axes Machine: X axis – Panel movement system along X direction made with a single auto-aligning suction cup. Y axis – Head movement along Y direction. Z axis – Head tools movement along Z direction. W axis – Panel slide bar movement. No. 18 drilling vertical spindles arranged in "T" formation. Panel dimension: Max (no limit x 35.4” x 2.16”) Min. (11.8” x 4.7” x ½”) No.1 Circular saw blade attachment with 1.8 Hp independent motor, speed 12,000 Rpm, to obtain grooves in X direction. No1. Router unit 7 Hp “Electrospindle” equipped with tool clamp type CPE for MANUAL tool change system. Adjustable speed 12,000-18,000 Rpm.
Shipping Footprint:	12 (length) x 5 (width) x 6 (height)
Weight:	4500 lbs

All Information including Photos and Videos are supplied by a 3rd party Source.
Please confirm all data before committing to a purchase.
*Subject to credit approval. Additional programs available.
