2003 Anderson Stratos Pro 5x12 Flat table CNC Router
Anderson 5x12 Stratus Pro! Heavy Duty and ready to work!
| MA ID: | RC3 - 12979 |
| Price: | Call For Price |
| Category: |
CNC Router (3-axis) |
| Manufacturer: | Anderson America |
| Model: | Stratos Pro |
| Year of Manufacture: | 2003 |
| Condition: | Very Good |
| Electric: | multi Voltage |
|
2003 Anderson Stratos Pro Flat Table CNC Router (5x12)
CALL FOR AVAILABILITY
ECHNICAL SPECIFICATIONS:
Andersen 15hp HSK 63F Air Cooled Spindle (0-24,000 rpm) 10 Tool Automatic Toolchanger Line Boring Unit ; 2 HP 4500RPM w/ 10 + 5 (L Shaped) Pattern = 13 Vertical Drills + 4 Horizontal Drills Automatic Oil lubrication Helical Rack and Pinion on X Axis Ballscrew Drives on Y and Z Axes Table size..3700 mm x 1600 mm (145” x 63”) Table Pop-Up Pins.. Vacuum Zones per Table; 2 Hand Held Remote Pendant
INCLUDES 25hp Becker Pump
Maximum Feedrate- X axis:80meters/min(3,150”/min) Rack/Pinion Y-axis: 30 meters/min (1,181”/min) Ball Screw Z-axis: 30 meters/min (1,181”/min) Ball Screw |
|
| Shipping Footprint: | 18 (length) x 8 (width) x 8 (height) |
| Weight: | 14500 lbs |
