Holzher Lynx 7510 Flat Table CNC Router

EXTREMELY LOW HOUR School machine!!

MA ID:	RC3 - 13269
Price:	Call For Price
Category:	CNC Router (3-axis)
Manufacturer:	HolzHer
Model:	Lynx 7510
Year of Manufacture:	2012, 2013, 2014
Condition:	Excellent
Electric:	multi Voltage
2012 Holzher Lynx 7510 CNC Router Model Lynx 7510, Series NBA20909 Phenolic flat vacuum work table Table size 2790 mm x 1350 mm (109.8" x 53.1") Usable table work area 2690 mm x 1300 mm (105.9" x 51.1") X-axis travel 3060 mm (120.4") Y-axis travel 1550 mm (61") Z-axis travel 325 mm (12.7") Max work piece thickness 195 mm (7.67") Max travel speed X & Y axis 70 m/min, Z-axis 20 m/min 6.5 kw (8.7 hp) air cooled electro router spindle motor 1,000-18,000 rpm spindle speed range HSK-63F spindle mount End mounted (12) space automatic tool changer (6) vertical boring spindles mounted in X-axis (4) vertical boring spindles mounted in Y-axis 32 mm drill centers 1.7 kw (2.2 hp) boring unit drive motor 1,000-6,000 rpm boring spindle speed range Cantilever router design (1) Becker freestanding table vacuum pump type VTLF250 Freestanding electrical and control cabinet Hand held router head positioning pendant Flat screen color monitor Windows computer operating system Holz Her CNC software on computer front safety floor mat Machines have been moved to our warehouse in Hudson, NH 03051 We have 3 of these machines, all with the same spec, all with low hours (school machines)
Shipping Footprint:	17 (length) x 8 (width) x 8 (height)
Weight:	7500 lbs
