Alfa T300 Automatica Vertical Miter Saw
2011 Alfa T300 Automatica Automatic Vertical Miter Saw Cutting Process Machine
| MA ID: | SCM - 13195 |
| Price: | $16,000.00 |
| Category: |
Cutoff/Miter/Toe Notchers |
| Manufacturer: | Other manufacturer |
| Model: | T300 |
| Year of Manufacture: | 2011 |
| Condition: | Very Good |
| Electric: | 230 Voltage 60 Cycle 3 Phase |
|
Alfa Vertical Miter Saw
Specifications: High speed cutting to produce up to 500 frames per hour (based on 100 x 150mm frames.) For 45 degrees cuts on picture frames, doors, windows and furniture profiles. Min external size 110mm Max external size 1150mm Max width 50mm Max height 55mm 2 x 1.5kw saw motors 300mm max blade diameter Horizontal hopper feed unit to hold approx. 20 lengths Windows based color touch screen controller with RS232 / USB connections 4 different cut sizes per program to optimize cuts and reduce scrap Outfeed belt conveyor for cut pieces Step #1 – Vertical Material Feeder Step #2 – Material Loading – Material is automatically loaded to be cut from the feeder. Step #3 – A Material Gripper System is used to provide molding part movement into the Saw Cutting Station Step #4 – Double Miter Saw Cutting – Double Miter Cutting – Equipped with a Speed Feed Servo System, the TA-300 has a production output range from 1,500 to 1,900 cut pieces per hour. A Vertical and Horizontal Clamping System within the cutting station firmly holes the molding during the cutting process. Step #5 – Part Unloading Belt – Belt allows the removal of Cut Pieces (and division of those pieces….meaning sending one part one way and the other part elsewhere) Equipped with “Part Present” Photocell
|
|
| Shipping Footprint: | 12 (length) x 12 (width) x 5 (height) |
| Weight: | 2000 lbs |
Please confirm all data before committing to a purchase.
*Subject to credit approval. Additional programs available.
