New SCM Class TF 130 Fixed Shaper
Set up precision and reliability.The operator easily adjusts every movement thanks to the handwheel with mechanical readout
| MA ID: | SHM - 13314 |
| Price: | $13,400.00 |
| Category: |
Manual Single/double Shapers |
| Manufacturer: | SCM (SCMI) |
| Model: | Class TF 130 |
| Year of Manufacture: | 2023 |
| Condition: | New |
| Electric: | 230 Voltage 60 Cycle 3 Phase |
|
SCM Shaper
Specifications: Spindle height diam. 30-35 (40-50) mm 140 (180) Spindle speed (at 50 Hz) rpm 3000/4500/6000/7000/10000 Max. diameter of the profiling tool mm 250 Max. tool diameter retractable under the table at 90° mm 300 Max. diameter of the tenoning tool mm 300 Three-phase motor power starting from kW/Hz 7 (8) / 50 (60) Set up precision and reliability.The operator easily adjusts every movement thanks to the handwheel with mechanical readout positioned on the machine front. |
|
| Shipping Footprint: | 6 (length) x 6 (width) x 5 (height) |
| Weight: | 1500 lbs |
