DIMTER OPTICUT 90 XL OPTIMIZING CUT OFF SAW PUSH FEED
DIMTER OPTICUT 90 XL OPTIMIZING CUT OFF SAW PUSH FEED
| MA ID: | OSS - 13490 |
| Price: | Call For Price |
| Category: |
Optimizing Saws and Stop Systems |
| Manufacturer: | DIMTER |
| Model: | S90 XL |
| Year of Manufacture: | 2007 |
| Condition: | Very Good |
| Electric: | 460 Voltage 60 Cycle 3 Phase |
|
GREAT SAW FOR THOSE WIDE CUTS NEEDED UP TO 14.25" RUNS GREAT
GREAT PUSH FEED SAW FOR UP TO 14'5" PRODUCTION Working dimensions: Width 2" to 9.875"; thickness 3/8" to 2" and length 3' to 14-3/4" (4.5M). Machine length 48'; feeds right to left. Motor: 10 HP saw motor at 4,800 RPM. with 16" saw blade. Feed: Variable speed up to 750 FPM with return up to 590 FPM. Pusher: Automatic pusher arm controlled by servo motor that travels the length of the board measuring: length, grade zones, and defects. Positioning accuracy to +/- 1 mm. Swivelling positioning pusher with photo eye for automatic length detection. Software: OPTICOM DIRECT control system with 12" color "touch" screen. Controls for: maximum yield, maximum value, quantity of pieces, diagnostics. (100) board groups with (8) grades. Auto width measuring. Ethernet connection. Sort line: Driven by a 2 hp motor with outfeed belt 10" x 32' with (2) mechanical kickers for sorting as inputted from the OPTICOM DIRECT. |
|
| Weight: | 10000 lbs |
Please confirm all data before committing to a purchase.
*Subject to credit approval. Additional programs available.
