Biesse Roxyl 5.5 Edgebander
A well kept machine out of a beautifully kept shop.
| MA ID: | EBS - 13508 |
| Price: | $45,000.00 |
| Category: |
Edgebanders -Single Sided |
| Manufacturer: | Biesse |
| Model: | Roxy 5.5 |
| Year of Manufacture: | 2014 |
| Condition: | Very Good |
| Electric: | Multi Voltage 60 Cycle 3 Phase |
|
Biesse Roxyl 5.5 Single Sided Edgebander
Capacity; Edge thickness; strips (0.4 - 22mm) Edge Thickness; coiled stock; (0.4 - 3mm) Panel thickness; 10 - 60 mm (0.39 - 2.36") Work piece width min.;85 mm (3.34") Work piece length min.; 140 mm (5.51") Feed speeds 10 - 14 - 18 - 20 MPM (33 - 46 - 59 - 65 FPM) Machine Layout Motorized top beam positioning Adjustable infeed fence Pre-Milling Station "FL-502": (2) LH & RH Rotating NC controlled spindles with automatic center positioning. Infrared Heating Lamp: Preheating workpiece edge to ensure best possible surface adhesion EVA (Hot Melt) gluepot, equipped with quick pre-melting Pressure Section: Servo controlled programmable pressure section with (1) large driven roller and (4) idle rollers. End Trimming; Front & rear trimming motors, swivel to 0° - 15° bevel, programmable pneumatic change Rough Trimming (first set); Top/Bottom pre- or flush trimming motors Fine Trim/Bevel/Radius Trimming; Servo controlled, pneumatic pre-positioning of motors Corner Rounding; (2) Motor corner rounding Profile Scraping; Top/Bottom 2-axis NC programmable knife positioning Glue Scraping; Flat, top/bottom, digital positioning indicators, pneumatic controlled positioning Buffing; Top & Bottom buffing motors with 150 mm (6") cloth buffing wheel. fully adjustable Hot air blowers Overhead belt hold down Centralize lubrication system External multitap transformer
New machine is in! Motivated seller!! |
|
| Shipping Footprint: | 24 (length) x 5 (width) x 6 (height) |
| Weight: | 7000 lbs |
Please confirm all data before committing to a purchase.
