Brandt KDF 530C Edgebander
This model is well equipped. It has Premill, Corner Rounding and also has Servo Control on top/bottom trim stations. Ready Now!
| MA ID: | EBS - 13655 |
| Price: | $13,500.00 |
| Category: |
Edgebanders -Single Sided |
| Manufacturer: | Brandt |
| Model: | Optimat KDF 530C |
| Year of Manufacture: | 2007 |
| Condition: | Good |
| Electric: | Multi Voltage 60 Cycle 3 Phase |
|
Brandt Optimat KDF 530C
Machine Description: Edge Capacity; 0.4 - 8 mm (1/64" - 5/16") Panel Thickness; 12 - 55 mm (1/2" - 2-3/16") Minimum Panel Length; 160 mm (6-3/8") and Minimum Panel Width; 65 mm (2-1/2") Equipped with Integrated Line control - No limit switches used for setting workstation function. Joint Trimming Unit (Premill) of the workpiece prior to gluing; (2) 3 HP motors - (1) Clockwise and (1) Counterclockwise, 12,000 RPM; Vertical spindle via digital settings - Horizontal positioning via electro-pneumatic control Panel Pre-heater; A quartz heater pre-heats the panel edge for better glue adhesion Universal Automatic Magazine for Strip and Coil Feeding with a strengthened pre-cutter for cutting PVC from the coil - 800 mm Diameter coil table for large 3 mm PVC coils. Quick heat up Granulate Gluing System with "quick change tank” for easy maintenance and glue color change, includes reversible rotation of glue application roller. Post application Glue heat; Maintains temp for better adhesion. Pressure Section with (1) large driven pressure roller and (2) secondary rollers with controlled side pressure End trim Station; Straight or Chamfer 0 to 15° - (2) 1/4 HP - 12,000 RPM motors; program-controlled indexing from straight to bevel end trimming. Fine Trimming Station; (2) ¾ HP - 12,000 RPM motors; Servo Motor Positioning of the side copy rollers Contour Trimming Unit; (1) ½ HP - 12,000 RPM motor; For corner rounding of thick PVC Edges Scraping Station with Knives; For scraping of roughly trimmed PVC edges to remove cutter marks; program controlled pneumatic indexing. Top & Bottom Buffing Station - 2,800 RPM motors, inclinable vertically and horizontally Feed chain track speed - (2) Speeds: 36 fpm when contour trimming, otherwise 46 fpm-(15mpm) 3 HP feed drive Equipped with digital height indicator, Electronic Frequency Changer for all trimming motors. Comes with a multi-tap transformer. |
|
| Shipping Footprint: | 26 (length) x 6 (width) x 6 (height) |
| Weight: | 4500 lbs |
Please confirm all data before committing to a purchase.
*Subject to credit approval. Additional programs available.
