2005 Holzher 1488 Triathlon Edgebander.
FEATURES: - Patented “Granu-Press Glue System”
- Heavy duty feed motor with feed chain guide for smooth workpiece advance
- Pressure beam with double sided and centralized height adjustment PPC controlled.
- Wide workpiece support area
- Safety enclosure of all cutting areas with electronic lockout.
- Central Dust extraction outlet.
Model 1488 Triathlon equipped with the following units: PPC mini PC controller - Ability to program all edgebander functions including: panel thickness, pre-milling, edge feed, glue application, end trimming, flush trimming, radius trimming, scraping, shaping, corner rounding, sanding, and buffing (according to units and options purchased with machine).
- Programs can be easily created and recalled at will.
- Screen with graphic interface makes programming easy.
- A picture of each unit may be brought up on the screen to show the operator the status of the unit and the parameters which can be programmed.
- Virtually eliminates set-up time by merely selecting and loading a program, which automatically activates all required edgebander functions simultaneously.
- Each program clearly indicates on screen the units included and their exact settings.
- Programs can be modified easily to create new programs.
- Edgebander can be operated manually when required, without necessity to write a program.
- Eliminates use of limit switches and their normal adjustments related to work station activation along the feed track.
- Error messages are presented in plain text, to avoid the need for endless error code lists.
- Eliminates many mistakes caused by lack of operator skill.
- Latest technology offering many exclusive features and demonstrating HOLZ-HER’s continued leadership in the market.
MODEL 1901 EDGESTRIP MAGAZINE - 1 (one) universal magazine for solid edges, strips, and coiled material.
- Utilizes motion detector to ensure accurate, trouble-free positioning of edge material.
- Exclusive “TRACTOR-BELT FEED SYSTEM” to ensure accurate, trouble-free feeding of edge material, as well as optimum operator safety.
- Angled strip gate to prevent double feeding of strips.
- Magazine table on rollers for smooth feeding of coiled material.
- Edge guide equipped with automatic guillotine lock-out for safety.
- “3 DEGREE APPROACH ANGLE” allows easy feeding of large wood edges.
- Automatic guillotine for coiled material up to 4.0 mm.
MODEL 1907 GLUING STATION - “ULTRA-GRANUPRESS SYSTEM” Includes servo motor adjustment for glue height - Equipped with HOLZ-HER'S exclusive patented "GRANULATE" glue system. This is a CLOSED APPLICATION SYSTEM in which the glue is enclosed in an air- tight chamber and cannot oxidize, discolor, burn, or become contaminated with wood dust. This allows for optimum glue adhesion.
- Glue applied to panel by patented GLUE NOZZLE from 6-60mm workpiece thickness.
- Precise control of all functions including begin and end of glue line, height of glue line, bottom of glue line, volume of glue and face melt temperature.
- Programmable Logic Control for feed speed changes.
- Less maintenance - no glue pot to clean, fewer parts.
- Efficient glue consumption - virtually no waste.
- Efficient power consumption - uses less than half that of conventional glue pots.
- Fastest & easiest glue color change, 5-10 min.
- Fastest heat-up time in the industry, 3-5 min.
- No fumes or other environmental hazards.
- Machine can be used for trimming without heating up the glue section.
MODEL 1926-M MOTORIZED PNEUMATIC PRESSURE SECTION - With 3 individually controlled pressure rollers pneumatically synchronized to panel leading and trailing edge.
- One of the rollers is cylindrical and two are slightly conical to provide maximum pressure at the top, bottom, and middle of the edgestrip.
- Motorized adjustment for edgeband thickness automatically controlled via PPC controller.
MODEL 1916.3 END-TRIMMING UNIT HIGH FREQUENCY AUTOMATIC SWIVEL - End Trim Unit complete with (2) 3/4 HP motors running on solid, polished bars with linear bearings and heavy rigid motor mounts for precision trimming. (up to 20 mm thick)
- “Uni-Point” swivel system for quick change from flush to bevel trimming without adjustments for blade changes.
- With 2 TCT saw blades (Diameter 160 x 30 x 3.2 mm, 24 teeth).
- With retreat action for a reduced workpiece interval.
- With 2 x 0.55 KW motors, 230 V, 60 HZ.
- Cutting Speed = 6,600 RPM.
- Includes 3 Siko digitals for quick set-up.
- Track speeds:
- For Feed 22 m/min up to 10mm thick
- For Feed 20 m/min up to 15mm thick
- For Feed 16 m/min up to 20mm thick
- For Feed 8 m/min up to 30mm thick
MODEL 1962 MOT1 HIGH FREQUENCY FLUSH TRIMMER - For high production flush trimming of all edge materials including heavy lumber band.
- Edge Thickness Capacity = 20 mm = 3/4”.
- Motors 2 x 2.0 KW, (2.682 HP), 200 HZ
- Cutterhead Speed = 12,000 RPM.
- Integrated vertical copy wheels.
- NO TILT CAPABILITY.
- Digital readouts for quick adjustments included as standard.
- All cutterheads are “insert carbide” to ensure accuracy, repeatability, and ease of set-up
- Servo adjustment of entire station in or out
MODEL 1966-M HIGH FREQUENCY FLUSH TRIMMER (5 axis Servo Control) - For high production flush trimming of all edge materials including lumber band.
- Edge Thickness Capacity = 15 mm = 5/8” (depending on tooling).
- Programmable unit functions through PPC programming via five axis servo-motors.
- Automatic unit positioning via PPC control.
- Motors 2 x 1.0 KW, ( 1 1/2HP),200 HZ
- Cutterhead Speed = 12,000 RPM.
- Bevel Capability = 0 - 45º (depending on tooling).
- Integrated vertical and horizontal copy wheels. .
- Uses multi-purpose insert carbide heads for flush, bevel, and radius trimming.
(flush, bevel, 1 mm, 2 mm, 3mm, 5mm radius possible depending on tooling) - All adjustments completely programmable through the PPC.
MODEL 1983 CONTOUR TRIMMING UNIT, H.F. WITH AIR JET - For rounding of corners: radius, chamfer, or flush trim.
- Servo Controlled
- Possible radius: 2 mm and 3 mm.
- Four motor, 1 x 0.6 KW, 300 HZ.
- Feed speed of 12 meters per minute. Max.
- Includes 7 Siko digitals for quick set-up.
- Equipped with reversible blade cutterhead with radius knives.
MODEL 1929 SCRAPER UNIT - Uses reversible insert carbide scraping knives on the top and bottom edges.
- Normally equipped with radius tooling to finish and remove knife marks created by the top, bottom, and radius units on thick PVC edgings. (2,3 mm).
- Equipped with air-jet blowers.
- Vertical and horizontal copy wheels.
- Equipped with digital readouts for all adjustment spindles.
- “PCS” Pneumatic Changeover System moves Scraper Unit in and out from control panel.
- Chip Collector Box
MODEL 1964 FINISH SCRAPER - Flat knives scraping along board/banding joint
- Clean up any glue squeeze out
- Pneumatic engage/disengage vi aPLC
- Plunge-in controlled top and bottom separately, incl. 2 blow nozzles, 2 turnover knives and 2 replacement turnover knives
MODEL 1944 PLUNGE BUFFING UNIT - Includes two motors with the possibility of adjustment in any direction.
- Incorporates “plunge control” to avoid rounding-over the leading and trailing edges, and ensure tight corners (thick PVC).
- Vertical Tilt = 0 to 45 degrees.
- Horizontal Swivel = 0 to 20 degrees for longer cloth wheel life and better edge buffing.
- Cloth buffing wheels for smoothing the sharp edges of thin PVC band after trimming.
- Can be equipped with fine sanding wheels for finishing wood and laminate edges.
- Motor Speed = 1440 RPM.
TECHNICAL DATA: Edgestrip Thickness; 0.4 to 25 mm = 0.016 to 1 in. Edgestrip Height Max.; 66 mm = 2 5/8 in. Panel Length Min.; 140 mm = 5.5 in. Variable Feed Speed; 12mm to 22 meters per minute Compressed Air Required; 90 PSI @ 3 CFM Connected Load; 80 Amps at 230 V. 3 phase
|
